Jasic EVO MIG 160 PFC Multi Process Compact Inverter Package 95-265V - Model No: EM-160C

Advanced 160A multi process inverter welder with synergic control, wide voltage input, and PFC technology for professional fabrication, maintenance, and site work.

Product Overview

The Jasic EVO MIG 160 PFC is a next generation compact inverter welder offering MIG, MMA, and Lift TIG capability in one versatile unit. Featuring intelligent synergic control, it automatically optimises settings based on welding parameters, delivering consistent, high quality welds with minimal setup time.

Designed for both workshop and site use, the wide 95–265V input range with power factor correction (PFC) ensures reliable performance even with generator power. Its durable build, digital display, and advanced control features make it ideal for professional users requiring flexibility, portability, and precision.

Key Features

  • MIG, MMA and Lift TIG multi process capability
  • Intelligent synergic control for automatic parameter setup
  • Power Factor Correction (PFC) – generator friendly
  • Wide voltage input range (95–265V) for site and workshop use
  • ClearVision digital display for improved visibility
  • Welding engineer mode for advanced control adjustments
  • Variable inductance control for arc tuning
  • Smart Lift TIG functionality
  • Fan on demand and auto sleep mode for energy efficiency
  • LED lit wire feeder cabinet with internal storage
  • Voltage Reduction Device (VRD) for safety in MMA mode
  • Overcurrent and overheat protection systems

Technical Specifications

  • Input Voltage: AC 95–265V, 50/60Hz (single phase)
  • MIG Current Range: 20–160A (230V)
  • MMA Current Range: 20–140A
  • TIG Current Range: 5–160A
  • Duty Cycle: approx. 30% @ 160A
  • Wire Feed Speed: 2–14 m/min
  • Wire Spool Size: 200mm (5kg)
  • Efficiency: approx. 84%
  • Power Factor: approx. 0.99
  • Protection Class: IP23S
  • Dimensions: 565 × 220 × 415mm
  • Weight: approx. 16kg


What’s Included

  • EVO MIG 160 PFC inverter power source
  • 3m MIG torch
  • Earth return lead and clamp
  • Gas hose and regulator
  • V groove feed rollers (0.8 / 1.0mm)

Optional Accessories

  • Spool gun for aluminium welding
  • TIG torch for Lift TIG welding
  • Remote control systems
  • Inverter trolley and storage solutions
BrandJasic
Ouput Amperage160
Power Supply95-265V
GeneratorYes
Materials WeldedSteel/Stainless Steel
Material Thickness (mm) (Steel/St/St/Alum)5/4/
Application/UseDIY/Light Trade
