Composite Panel to Light Section Steel

Hex Composite Panel to Light Section Steel Bi Metal Self Drilling Screw with EPDM Washer Stainless Steel A2 Silver Organic Plated

These bi metal self-drilling screws are specifically designed for fixing composite panels to light section steel up to 5 mm thick without the need for pre drilling. A self-drilling point combined with a hexagon head and split thread delivers fast, secure installation and reliable pull through resistance. An integral EPDM sealing washer provides a weathertight seal at the fixing point, making the screw suitable for external cladding applications.

The hardened carbon steel drill tip is permanently fused to an A2-304 austenitic stainless steel body, offering the drilling performance of carbon steel with the long term corrosion resistance of stainless steel. The silver organic coating further enhances durability, making these fixings ideal for exposed and demanding external environments commonly found in roofing and cladding installations.

Key Features

Bi metal self-drilling composite panel screw
For fixing composite panels to light section steel (max. 5 mm)
Hardened carbon steel drill tip fused to A2-304 stainless steel body
Hexagon head with split thread for secure fixing
EPDM washer provides weatherproof sealing
Silver organic plated for enhanced corrosion resistance

Applications

Composite cladding panels
Roofing and wall panel systems
Light gauge steel frameworks
External building envelope installations

Composite Panel to Light Section Steel

Diameter

Head Type

Length

Material

5.5/6.3x70 Hex Composite Panel to Light Section Steel Bi Metal Exterior Self Drilling Screw and Wash

5.5/6.3x82 Hex Composite Panel to Light Section Steel Exterior Self Drilling Screw and Washer Silver

5.5/6.3x98 Hex Composite Panel to Light Section Steel Exterior Self Drilling Screw and Washer Silver

5.5/6.3x100 Hex Composite Panel to Light Section Steel Bi Metal Exterior Self Drilling Screw and Was

5.5/6.3x115 Hex Composite Panel to Light Section Steel Exterior Self Drilling Screw and Washer Silve

5.5/6.3x150 Hex Composite Panel to Light Section Steel Exterior Self Drilling Screw and Washer Silve
